Deskripsi Produk
Untuk mengenalkan dan memberi keterampilan mengerjakan benda kerja menggunakan mesin sekrap.
Maximum distance from ram bottom to table surface : 330 mm
Maximum table horizontal travel : 400 mm
Maximum table vertical travel : 270 mm
Leading surface of the planer to bed out of the maximum distance : 550 mm
The maximum displacement of the ram : 170 mm
Maximum turning angle of the worktable (no vice) : +90°
Maximum turning angle of the worktable (vice) : +55°
The turret maximum vertical travel : 110 mm
Number of ram strokes per minute : 32, 50, 80, 125, times min The ram back and forth a table feed amount
Wheeled round a tooth (vertical) : 0.18 mm
Wheeled round a tooth (horizontal) : 0.21 mm
Wheeled round 4 tooth (vertical) : 0.73 mm
Wheeled round 4 tooth (horizontal) : 0.84 mm
Electric : 1.5 kW 1400 r/min
Standard accessories : Transmission belt, Inner hexagon spanner, Crank handle, Spanner, Oil gun, Foundation bolts, Random technical
