Deskripsi Produk

Master Making / Printing MethodsHigh-speed digital master-making/Fully automatic printingOriginal typeSheetOriginal Size (min./max.)90 mm x 140 mm to 310 mm x 435 mm
(3 17/32 inches x 5 1/2 inches to 12 7/32 inches x 17 1/8 inches)Original Paper Weight50 gsm to 107 gsm (13-lb bond to 29-lb bond)Original Paper Capacity1 SheetScanning Area (max.)297 mm x 435 mm (11 11/16 inches x 17 1/8 inches)Printing Paper Size (min./max.)100 mm x 148 mm to 297 mm x 420 mm
(3 15/16 inches x 5 13/16 inches to 11 11/16 inches x 16 17/32 inches)Paper Supply CapacityApprox. 1000 sheets, 64 gsm to 80 gsm (17-lb bond to 21-lb bond)/Maximum stacking height: 110 mm (4 11/32 inches)Paper Receiving CapacityApprox. 800 sheets, 64 gsm to 80 gsm (17-lb bond to 21-lb bond)/Maximum stacking height: 90 mm (3 17/32 inches)Printing Paper Weight35 gsm to 128 gsm (9-lb bond to 34-lb bond)Image Processing ModeLine, Photo, Duo, PencilResolution
(Scanning and Printing)300dpi x 300dpiMaster-making TimeApprox. 39 seconds or less (for B4 originals/short edge feed/100% reproduction ratio)Printing Area (max.)In units of mm: 251 mm x 357 mm (9 7/8 inches x 14 1/16 inches)
In units of inches: 210 mm x 349 mm (8 9/32 inches x 13 3/4 inches)Print Reproduction RatioIn units of mm: 100% reproduction ratio, Enlargement (141%, 122%, 116%), Reduction (94%, 87%, 82%, 71%)
In units of inches: 100% reproduction ratio, Enlargement (154%, 129%, 121%), Reduction (94%, 78%, 65%, 61%)Print Speed3 levels: 60, 80, and 100ppmPrint Position AdjustmentHorizontal:±10 mm Vertical:±10 mm*1, (Horizontal: ±13/32 inches, Vertical: ±13/32 inches)Ink SupplyFull automatic (800 ml/cartridge)Master Supply/DisposalFull automatic (B4: approx. 200 sheets per roll)/Disposal capacity: approx. 30 sheetsUser InterfaceLED panelComputer ConnectionUSB PC InterfaceOptional AccessoriesNot AvailableOperating NoiseMax. 69dB(A) (when printing 100 sheets per minute in the operator position)Power SourceAC100-120V/220-240V, 50-60 Hz <2.0A/1.0A>Power ConsumptionMax. 160W, Ready: 15W or lower, Sleep: 10W or lower, Power-OFF: 0.5W or lowerFunctionsOriginal Scanning Mode, Scanning Level, Enlargement/Reduction, 2-Up, Speed, Print Position, Program, Idling, Confidential, Meter Display, Proof, Direct Printing, Auto Sleep Setting, Auto Power-OFF Setting, RISO iQuality SystemDimensions (W×D×H)In Use1280 mm x 655 mm x 515 mm
(50 13/32 inches x 25 25/32 inches x 20 9/32 inches)In Storage665 mm x 655 mm x 505 mm
(26 3/16 inches x 25 25/32 inches x 19 7/8 inches)Required Space (W×D×H)1280 mm x 1255 mm x 845 mm
(50 13/32 inches x 49 13/32 inches x 33 9/32 inches)WeightApprox. 64 kg (141lb)*2
